FS-8700-104_ControlNet_X30 Manual Page 7 of 13
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: [email protected]
5.2 Server Side Connection Parameters
Section Title
Connections
Column Title Function
Legal Values
Adapter Adapter Name ControlNet
Example
// Server Side Connections
Connections
Adapter
ControlNet
5.3 Server Side Node Parameters
Section Title
Nodes
Column Title Function
Legal Values
Node_Name Provide name for node Up to 32 alphanumeric characters
Protocol Specify protocol used X30_CNet_Slave
Example
// Server Side Nodes
Nodes
Node_Name , Protocol
CN5 , X30_CNet_Slave
5.4 Server Side Map Descriptor Parameters
5.4.1 FieldServer Specific Map Descriptor Parameters
Column Title Function Legal Values
Map_Descriptor_Name Name of this Map Descriptor Up to 32 alphanumeric characters
Data_Array_Name
Name of Data Array where data is to be
stored in the FieldServer One of the Data Array names from
Section 4
Data_Array_Offset Starting location in Data Array
0 to (Data_Array_Length -1) as specified
in Section 4
Function Function of Server Map Descriptor
RDBC -Reads data from the local input
buffer
WRBC -Writes data to the local output
buffer
