ASSEMBLY
M3864pr-0920
Slots
Dash
• Fit the tabs on the back of the windshield into the slots in the top of
the dash.
• Fit the windshield into the windshield frame.
• Insert five #6 x
1 /
2
" screws into the holes in the windshield and tighten.
Windshield
Windshield
Frame
13
14
• Rotate the top of the windshield toward the front of the vehicle.
• Insert four #8 x 1" screws into the holes in the hinge on the windshield
and tighten.
Windshield
15
Hood
Grille
• Lift the hood.
• Fit the tabs at the bottom of the grille into the slots in the vehicle.
• Press near the top of the grille to snap it into the vehicle.
• Lower the hood.
16
Windshield
