3.3 DIP Switch Settings
The factory default settings are as follows:
1 2 3 4 5 6 7 8
ON
OFF
(*Note: the indicates the switch position)
DIP Switch Functions
SW
Function
ON state / OFF state
1
Hot Key Mode:
ON: enabled / OFF: disabled
2
Hot Key Mode: Double
ON: enabled / OFF: disabled
3
Hot Key Mode: Double
ON: enabled / OFF: disabled
4
Country Setting bit 1
(see following table)
5
Country Setting bit 2
( “ )
6
Country Setting bit 3
( “ )
7
Country Setting bit 4
( “ )
8
Power Mode Setting
ON:
the switch device is always ON.
OFF: the switch device turns ON if any connected
host is turned ON.
The country code (language) settings are as follows:
Country Setting
SW4
SW5
SW6
SW7
Japan
ON
ON
ON
ON
US
ON
ON
ON
OFF
UK
ON
ON
OFF
ON
German
ON
ON
OFF
OFF
French
ON
OFF
ON
ON
Spanish
ON
OFF
ON
OFF
Swedish
ON
OFF
OFF
ON
The country code (language) settings are as follows:
Country Setting
SW4
SW5
SW6
SW7
JPN
ON
ON
ON
ON
USA
ON
ON
ON
OFF
GBR
ON
ON
OFF
ON
GER
ON
ON
OFF
OFF
FRA
ON
OFF
ON
ON
ESP
ON
OFF
ON
OFF
SWE
ON
OFF
OFF
ON
POR
ON
OFF
OFF
OFF
TPE
OFF
ON
ON
ON
KOR
OFF
ON
ON
OFF
ITA
OFF
ON
OFF
ON
UNIX
OFF
ON
OFF
OFF
NOR
OFF
OFF
ON
ON
BEL
OFF
OFF
ON
OFF
DEN
OFF
OFF
OFF
ON
