ASSEMBLY F
H0438pr-0921
6
• Fit the front end onto the vehicle.
• Insert the tabs on the back edge of the front end into the slots in
the vehicle.
Front End
Vehicle
7
• Insert two #8 x 3 / 4
" screws through the front end and into the
vehicle. Tighten the screws.
Front End
8
• Insert two 1 / 4
" x 1 1 / 4
" screws inside of the battery compartment and
into the front end of the vehicle. Tighten the screws.
Battery
Compartment
9
• Fit the bumper onto the front end.
Bumper
Front End
TOP VIEW
RIGHT SIDE VIEW
