FUJITSU FTP-629MCL054 - Manual (Page 2)

2
FTP-629MCL054/353/354-R
n PART NUMbeRS
*: Interface is selectable by DIP switch
n GeNeRAL SPeCiFiCATiONS
Item Specifications
Part number FTP-629MCL054/074-R FTP-629MCL354/374-R
Printing method Thermal sensitive line dot method
Dot structure 432 dots/line
Dot pitch (horizontal) 0.25mm (8dots/mm) - Dot density
Dot ptich (vertical) 0.25mm (8dots/mm) - Line feed pitch
Effective printing area 54 mm
Number of columns ANK 36 columns/line (2 x 24 dot font), OCR 8 columns (24x40)
Paper width 60 mm +0/-
Paper thickness 60 to 50µm
(there may be exceptions)
60 to 00µm
Cutting type --- full or partial
Printing speed FTP-629DCL/DSL series FTP-629DSL00 series/
FTP-629DSL300 series
80mm/sec. (640 dot lines/sec.)
line mode
200mm/sec. (600 dot lines/sec.)
image mode
25mm/sec. (000 dot lines/sec.) line
mode
200mm/sec. (600 dot lines/sec.)
page mode
Interface types FTP-629DCL/DSL series
FTP-629DCL/DSL00 series
FTP-629DSL300 series
Character
types
Alphanumeric, Kana:
International and special
OCRI
OCRIII
OCRIV
Extended numeric
JIS Kanji level , level 2, non-Kanji
59 types
95 types
about 6,800 types
59 types
95 types
03 types
23 types
03 types
types
about 6,800 types
Character, dimensions (WxH), number of
columns
(8x6 dots), 54 columns: ANK
(2x24 dots), 36 columns: ANK
(6x6 dots), 27 columns: ANK
(24x24 dots), 8 columns: ANK
(24 x 40 dots), 8 columns, OCRI
(24 x 48 dots), 8 columns, OCRII
(36 x 60 dots), 2 columns, OCRIV
(24 x 48 dots) 8 columns, extended
numeric
Interface standard Centronics, RS-232C, USB Serial /USB
Name Part Number
Printer mechanism Bottom insertion FTP-629MCL054R FTP-629MCL074R FTP-629MCL054R
Mechanism with cutter Front insertion FTP-629MCL353R TBA FTP-629MCL353R
Bottom insertion FTP-629MCL354R FTP-629MCL374R FTP-629MCL354R
LSI FTP-629CU0R FTP-629SR20 FTP-629CU30R
Interface board Parallel FTP-629DCL04R FTP-629DSL8R*
Serial (RS232C) FTP-629DSL034R FTP-629DSL8R* FTP-629DSL30R
USB --- FTP-629DSL2R FTP-629DSL30R
Thermal head cable extension --- FTP-629Y00 ---
Interface cable Parallel FTP-628Y202 ---
Serial FTP-628Y302 FTP-629Y302
USB --- FTP-629Y30
Power supply cable Logic FTP-629Y40 ---
Head, motor FTP-629Y60 FTP-629Y602
