freeView IP 100 User’s Manual
C. Video Modes
Table C-1 lists the video modes supported by the freeView IP 100. Do not use custom video
settings besides that are not listed in the following table. Otherwise the freeView IP 100 may not
be able to detect them.
Resolution (x, y) Refresh Rates (Hz)
640 x 350 70, 85
640 x 400 56, 70, 85
640 x 480 60, 67, 72, 75, 85, 90, 100, 120
720 x 400 70, 85
800 x 600 56, 60, 70, 72, 75, 85, 90, 100
832 x 624 75
1024 x 768 60, 70, 72, 75, 85, 90, 100
1152 x 864 75
1152 x 870 75
1152 x 900 66
1280 x 960 60
1280 x 1024 60, 75
Table C-1: Supported Video Modes
D. Rack Mount Kit Installation Diagram
Figure D-1: Rack Mount Installation Diagram
79
