G57 Two-channel Power Amplifier

��

��

��
��

��
��

��

����

��

��
��
��

��

Use this output

To connect to this

LEFT, RIGHT

Loudspeakers of 2Ω to 16Ω, using either plug or bare wire connections.

FAN OUTPUT

A Meridian rack mount kit. This is a proprietary Meridian connection.

I n s t a l l i n g

t h e p o w e r

a m p l i f i e r

1 9

Each channel of the G56 or G57 Two-channel Power Amplifier
provides twin outputs for bi-wiring. This allows separate
connections to be made to the bass/mid and tweeter units on
speakers that allow bi-wiring, for optimum sound quality.

Alternatively, for loudspeakers providing a single pair of inputs,
either of the output terminals can be used.
