Quickstart
FS­100 Portable DTE Recorder 11
Computer FireWire Connector
• In/Out: 6­pin IEEE­1394a port x 1
• Asynchronous Data I/O
Remote Control, Serial Connector
• GPI / RS232C; 3.5mm TRS mini jack. (3.5mm to DB­9 cable
accessory available).
• Configure as a simple contact closure or RS­232C port.
• Connect an optional wired remote commander.
Camera FireWire Connector
• DV/I/O
• 6­pin IEEE­1394a connector
• Isochronous 25Mb/s DV video I/O
FS­100 supports 1080i/720p video I/O in DVCPROHD REC
mode.
• Supported inputs for DVCPROHD / DVCPRO50 / DVCPRO /
DV:
• For DVCPROHD input, audio is embedded 4­ch, 48kHz, 16­
bit.
• For DVCPRO50 input, audio is embedded 4­ch., 48kHz, 16­
bit.
• For DVCPRO input, audio is embedded 2­ch., 48kHz, 16­bit,
• For DV input, audio is embedded 2­ch., 48kHz, 16­bit or 4­ch.,
32­khz, 12­bit.
NTSC
­ 1080 60i (30P, 24P, 24PA)
­ 720 60P (30P, 24P)
­ 480 60i (30P, 24P, 24PA)
­ *( ) pull down format ­ (same stream)
PAL
­ 1080 50i (25P)
­ 720 50P (25P)
­ 576 50i (25P)
­ *( ) pull down format ­ (same stream)
4­Channel Audio
4­channel (12­bit, 32kHz) audio is available only with RawDV
format.
