• Fit the sport bar and sport bar support legs into the holes
in the vehicle body.
• Push down firmly on a sport bar side leg while pulling
up on the side fender to fit the sport bar into the
vehicle body.
• Repeat this procedure on the other side of the
vehicle body.
• Insert a 1 1 /
2
" x 1 /
4
" machine screw into the hole closest to
the front of the vehicle in the underside of the rear wheel
well, through the vehicle body and into the end of the
sport bar.
• Tighten the screw with a Phillips screwdriver. Do not
over-tighten.
• Repeat this procedure on the other side of the
vehicle body.
Sport Bar
Side
Fender
PULL HERE
PUSH
HERE
Rear Bumper
Support
Tabs
• Face the rear of the vehicle.
• Fit the lower rail on the rear bumper over the rear
bumper support.
• Gently bend the tabs at the bottom of the rear bumper
under the vehicle.
Rear Bumper
Lower Rail
36 34
• Align the tabs on the inside of a light cover with
the slots in one of the light housings on the
KC
TM light rack.
• Push firmly on the light cover to snap it to the
light housing.
• Repeat this procedure on the other side of the
KC TM light rack to assemble the other light.
Sport Bar
KC TM Light
Rack - Front Half
KC TM Light
Rack - Back Half
Tabs
• Position the sport bar upright, as shown.
• Fit and hold the front and back halves of the KC TM light
rack against the sport bar. Make sure the two KC TM light
rack halves are aligned, and that the screw holes in the
KC
TM light rack are aligned with the screw holes in the
canopy and the sport bar.
• Snap the tabs on the front half of the KC TM light rack into
the slots below the light housings on the rear half of the
KC
TM light rack.
• Insert two #6 x1 1 /
2
" screws through the holes in the back
of the KC TM light rack, through the sport bar, and into the
front half of the KC TM light rack.
• Tighten the screws with a Phillips screwdriver. Do not
over-tighten.
33
