System configuration – Furuno Network Sounder DFF3 User Manual
Page 7
vi
SYSTEM CONFIGURATION
Basic configuration shown with solid line.
100/110/115/
220/230 VAC
1
φ,
50/60 Hz
Network Sounder
DFF3
12-24 VDC
Low
Freq.
Transducer
High
Freq.
Transducer
Rectifier
PR-62
Speed/Temperature Sensor
ST-02MSB
ST-02PSB
Temperature Sensor
T-02MTB
T-02MSB
T-03MSB
DFF3
NETWORK SOUNDER
ST-BY
* HUB-100 (For NavNet)
HUB-101 (For NavNet 3D)
NavNet Series
NavNet 3D Series
HUB*
