• Plug the charger into a standard wall outlet.
Note: If power flow to the wall outlet is controlled by a
switch, make sure the switch is “ON”.
• Before first-time use, charge the battery for at least 18
hours. Never charge the battery longer than 30 hours.
Note: The battery must be upright while charging.
• Recharge the battery for at least 14 hours after each
use of your vehicle. Do not charge the battery longer
than 30 hours.
• Once the battery is charged, disconnect the charger
connector from the battery connector. Unplug the
charger from the wall outlet. The battery is now
ready to be installed in your vehicle. Please see the
Battery Installation section on page 16 for detailed
instructions on installing your battery. If your battery is
already installed in your vehicle, simply re-connect the
battery connector and motor harness connector, re-
assemble the pretend engine cover and lower the hood.
• If you are charging the battery for the first time, insert a
25 amp fuse into the battery.
Note: The top of the fuse will not be flush with the top of
the battery when properly installed.
• If you are recharging your battery, make sure the 25 amp
fuse already installed in the battery is in good condition.
Remove the fuse from the battery and look at it to make
sure it is not blown. Replace a blown fuse with a new
Power Wheels
® 25 amp fuse.
IMPO RTA NT
A 25 AMP FUS E MU ST
BE IN STAL LED IN TO P
OF B ATTE RY B EFO RE
TOY WIL L RE CHA RGE
OR O PER ATE
®
25 Amp Fuse
1 3
®
Battery Connector
Charger
Connector
2
• Squeeze the connector tabs on the charger connector
and plug it into the battery connector.
IMPORTANT NOTE! If you are recharging your battery,
you will first need to remove the pretend engine cover and
disconnect the battery connector from the motor harness
connector under the hood.
8
GOOD FUSE "BLOWN" FUSE
Battery Charging
