Page 20
Harness HN0365
4 - pin connector
4- pin connector
(CN0082)
To Pilot I
Shrink Tubing
or Wrap
Blue
Red
Purple
Black
Black
Blue
Pin A
Red
+12 Battery
Pin B
Purple +12 Ignition
Pin C
Black
Depth Sounder (-)
Pin D
Blue
Depth Sounder signal
Black
ECR 2152 03/07/02
(+12 vDC) (Ignition)
(Grnd)
(Depth Sounder ( - ))
(Depth Sounder Signal)
Red
Shield
Green
White
Brown
(+12 vDC)
(Ground)
Paddle Wheel triducer
