power factor pro manual
7
furman sound, llC.
1997 south Mcdowell Blvd.
Petaluma, California 94954-6919 usa
Phone: 707-763-1010
fax: 707-763-1310
Web: www.furmansound.com
e-mail: [email protected]
121304-E
Important note:
The Power Factor Pro must be the first AC power component connected to the AC mains!
regulators such as the furman ar-1215 or uPs systems such as the sB-1000 must be
connected to the Power factor Pro’s output. this is due to the fact that the Pf-Pro’s current
reservoir may hinder the performance of a regulator, and worst case may cause damage in
extreme power environments.
as long as the Power factor Pro is connected prior to the regulator or uPs both components
may be used.
SpecIfIcatIonS
Current rating:
12 amps (“e” versions 7 amps)
operating Voltage:
90 to 140 VaC (“e” versions 180 to 280 VaC)
over Voltage shutdown:
140 VaC typically (“e” versions 280 VaC typically)
Voltmeter accuracy:
±2 VAC, calibrated with internal trimpot adjustments
spike Protection Modes:
line to neutral, zero ground leakage
spike Clamping Voltage:
188 Vpk @ 3,000 amps (133 VaC rMs) (tested to
ul-1449 6,000 Vpk @ 3,000 amps)
response time:
1 nanosecond
Maximum surge current:
6,500 amps
noise attenuation:
40 dB @ 10 kHz
40 dB @ 100 kHz
100 dB @ 10 MHz
linear attenuation curve from 0.05 - 100 ohms line
impedance
transient Current reservoir:
45 amps peak
Mechanical:
dimensions:
Pf-Pro: 5.25” H (with feet) x 8.125” W x 12.5” d.
Pf-Pro r: 19 “ W x 11.63” d x 1.75” H
Weight: Pf-Pro: 11 lbs (5 kg). Pf-Pro r: 9.7 lbs (4.39 kg)
Power Consumption:
6 watts (resistive)
420 watts (reactive)
safety agency listings:
Ce, etl-C (pending)
