• Lift the front end of the vehicle.
• Slide the straight end of the steering column through the
hole in the lower steering linkage and out through the
hole in the vehicle body.
• Insert the curved end of the steering column into the
hole in the upper steering linkage.
• Position the vehicle body upright.
Lower
Steering
Linkage
Upper Steering Linkage
13
Handlebar
Sound
Box
Neck
• Position the handlebar with the neck facing down and
the handlebar curving toward you.
• Slide the soundbox onto the right end of the handlebar,
soundbox side first.
• Set the handlebar assembly aside.
14
Steering
Column
Assembly
Bottom View
Hole in
Vehicle
Body
15
• Position the handlebar so that the side with the three
holes and circular indentation faces up.
• Fit the neck against the bottom of the handlebar, with
the holes in the handlebar and neck aligned.
• Insert a 1 1 /
2
" screw down through each of the two outer
holes in the handlebar and then through the neck.
• Fit a lock nut on the end of each screw.
• Using pliers to steady the lock nuts, tighten each screw
with a Phillips screwdriver. Do not over-tighten.
13
Hole
Hole
Lock Nut
Lock Nut
Handlebar
Circular
Indentation
Neck
