11
6
7
• Slide a hex bushing onto the rear axle. The ring side of
the hex bushing should face out.
• Press firmly to fit all but the ring on the end of the hex
bushing into the rear wheel.
• Fit a cap nut on the end of the rear axle.
• Tap the cap nut with a hammer to secure it on the end of
the rear axle.
• Pull on the wheel to make sure the cap nut is securely
fastened.
• Repeat this procedure to assemble the other rear wheel
(with driver) to the other rear axle.
Cap Nut
Front Axle
Ring
Side
7 /
16
" (Large)
Washer
Round
Bushing
Hex
Bushing
Rear Axle
Ring Side
• Slide a large washer onto the front axle.
• Slide a round bushing onto the front axle, ring side first.
8
Assembly
• Fit a hubcap on the rear axle and slide it into the center
of the rear wheel.
Rear Axle
Hubcap
5
