Operating Menus
Model HS-4700-S User's Manual
21
APPLY TO
Apply the current channel option settings to
another channel. Select the choice box to apply the
channel number and click the APPLY TO button.
OK
Click to save system setup parameters and return to
the Main Menu.
CANCEL
Click to keep existing system setup options and
return to the Main Menu
PTZ
(
OPTION
)
The PTZ is an optional feature available on some cameras. This feature is not available on
the cameras supplied with the HS-4700-S system, but the system software is PTZ-ready.
Access PTZ (Pan Configure) from the Main Menu. Use this menu to select the address,
protocol, and baud rate for each camera.
Channel
CH1
Address
01
Protocol
Pelco-D
Baudrate
4800
CH1
APPLY TO
OK
CANCEL
Channel
Select a channel, 1, 2, 3, or 4.
Method
PTZ communication address settings: range is 00-
99. To use this address, it must be the same as the
PTZ address setting.
Protocols
PTZ communication protocols are: Pelco-D,
Pelco-P, B01, and Samsung.
Baud Rate
PTZ baud rate settings are: 1200 /2 400 / 4800 /
9600 / 19200 / 38400 / 57600 / 115200.
APPLY TO
Apply the current channel options settings to
another channel. Select the choice box of the
channel number to the applied, and click the
APPLY TO button.
OK
Click to save system setup options and return to
Main Menu.
CANCEL
Click to keep existing system setup options and
return to Main Menu.
