First Alert HS-4700-S - Manual (Page 17)

Operating Menus
Model HS-4700-S User's Manual
13
R ECORD P ARAMETERS (R EC P ARA )
Channel
Name Brightness
Quality Contrast
FrameNum Saturation
CH1
CH1
LOW
50
50
15 50
APPLY TO CH1
OK CANCEL
Channel Select channel 1, 2, 3, or 4.
Name User-defined channel name.
Quality Select one of five video quality options: minimum,
low, medium, high, and highest.
Frame Num Select one of six frame options: 01, 03, 05, 10, 15,
and 30 fps (frames per second).
Brightness Set range from 00-99; default setting is 50.
Contrast Set range from 00-99; default setting is 50.
Saturation Set range from 00-99; default setting is 50.
APPLY TO Set current channel options and apply to other
channels; select a channel number, then click the
APPLY TO button.
OK Click to save system setup options and return to the
Main Menu.
CANCEL Click to keep existing system setup options and
return to Main Menu.
