Operating Menus
Model HS-4700-S User's Manual
20
Set To select the area of display that will trigger
Motion Detection.
Duration Indicates the length of record time. Set from 05 to
99 seconds.
Level Select the record video quality: Lowest, Low,
Middle, High, Highest.
Buzzer Triggers buzzer to alarm. "X" indicates function is
active.
Timer Indicates the length of time the buzzer will
continue output. Set from 00 to 99 seconds time.
APPLY TO Apply the current channel parameter settings to
another channel. Select the choice box of the
channel number that you want to set, and click the
APPLY TO button.
OK Click to save system setup parameters and return to
the Main Menu.
CANCEL Click keep existing system setup parameters and
return to the Main Menu.
M OTION S CHEDULE
Select Motion Schedule on the secondary menu, and enter the settings options.
Channel
Mon
Wed
Fri
Sun
CH1
APPLY TO
OK CANCEL
0 6 12 18
CH1
Red : On Green :Off
Channel Select the channel: 1, 2, 3, or 4.
Method There are 7 rows (for 7 days) and 24 columns (for
24 hours) in the interface box. Rows indicate
Monday to Sunday and columns indicate 00:00
o'clock to 23:00 o'clock. Press the Menu button on
front panel or click left mouse buttons to select a
day-hour box. Green indicates not selected; red
indicates selected.
Note: HS-4700-S system uses military time (24-hour clock).
