FORD Ranger - Manual (Page 231)

Roadside Emergencies
231
[RE21151(ALL)04/94]
10-1/2 pica
art:0021188-A
* [RE21200(ALL)05/95] RWARNING
To lessen the risk of personal injury, do not put any part
of your body under the vehicle while changing a tire. Do
not start the engine when your vehicle is on the jack.
The jack is only meant for changing the tire.
* [RE21400(ALL)06/95] 2. Remove the lug nuts with the lug nut wrench.
* [RE21500(ALL)06/95] 3. Replace the flat tire with the spare tire.
* [RE21700(ALL)06/95] 4. Thread the lug nuts on the wheel studs with the beveled
face toward the wheel. Use the lug nut wrench to screw the
lug nut snug against the wheel but do not tighten.
* [RE22200(ALL)01/95] 5. Lower the vehicle by turning the jack handle
counterclockwise.
* [RE22300(ALL)06/95] 6. Remove the jack and fully tighten the lug nuts in the order
shown in the following illustration.
