FUJITSU CardMinder P2WW-2640-01ENZ0 - Manual (Page 20)

2.1 CardMinder Window
20
Select the range containing a person’s full name or company name in the card image
to be re-recognized, and click the corresponding button,
or . The re-recognition process takes place over the
selected range only, and the OCRed text is overwritten in the corresponding field.
• Status Bar
Shows the following information. You can also switch between showing and hiding
the information.
− Number of selected cards
− The position of the selected card data/the number of cards shown in the Card
Data List pane
− Selected folder
− Recognition language
− Image magnification (display magnification of the selected card image)
− Zoom slider (slider used to change the display magnification of the card image)
Ribbon Buttons
The names and functions of buttons shown in the Ribbon are as follows:
•
[Home] tab
Button icon Button name Description
Scanner
Clicking scans cards with a scanner.
Clicking switches between Simplex and
Duplex scanning mode.
When is clicked, the [Scanner
settings] dialog box appears, and scanning settings
can be specified.
Recognize
Clicking recognizes card data by the
selected language.
Click to select the recognition lan-
guage.
E-mail Sets the e-mail address shown in the Edit Data pane
as the e-mail recipient address, and starts the e-mail
software.
If multiple card data is selected, sets multiple e-mail
recipient addresses, and starts the e-mail software.
