Fujitsu Siemens Computers LOOX 400 User Manual
Page 34
Operating the Pocket PC
26
A26391-K150-Z120-1-7619, Edition
3
The charging time is approx. 4 hours. When the battery is fully charged, the power-on indicator lights
continuously green.
Connecting PSC11R-050 power adapter to Pocket PC with adapter
3
2
1
►
Connect the adapter (1) to the ActiveSync port of the Pocket PC.
►
Connect the power adapter cable (2) to the adapter.
►
Connect the PSC11R-050 power adapter (3) to an electrical outlet.
The installed battery will now be charged. The power-on indicator (number 10 in the section
"Overview of operating elements and connections") flashes green.
The charging time is approx. 4 hours. When the battery is fully charged, the power-on indicator lights
continuously green.
