5.3.3 Map Descriptor Example
// Client Side Map Descriptors
Map_Descriptors
Map_Descriptor_Name , Data_Array_Name , Data_Array_Offset , Function , Node_Name , File_Type , File_Number , Address , Length , Scan_Interval
CMD_AI_01
, DA_AI_01 , 0 , Rdbc , PLC_01 , N , 10 , 0 , 16 , 1.0s
CMD_AO_01 , DA_AO_01 , 0 , Rdbc , PLC_01 , N , 11 , 0 , 16 , 1.0s
Map_Descriptors
Map_Descriptor_Name , Data_Array_Name , Data_Array_Offset , Function , Node_Name , File_Type , File_Number , Address , Length , Scan_Interval
CMD_DI_01
, DA_DI_01 , 0 , Rdbc , PLC_01 , B , 12 , 0 , 16 , 1.0s
CMD_DO_01 , DA_DO_01 , 0 , Rdbc , PLC_01 , B , 13 , 0 , 16 , 1.0s
update File_Number in section 4.4.2 and 5.3.2 limit should be 0-65535
along with a note that "Other device might not be supporting the full range, e.g. SLC5 supports only 0-255 and latest PLC5 till now supports only 0-1999"
