FS-8704-07 Allen Bradley PCCC (TCP/IP) Driver Manual Page 15 of 15
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: [email protected]
Appendix C. Reference
Appendix C.1. Command Support
The following commands are supported by the FieldServer for the various PLC types:
PLC_Type File_Type FNC Read FNC Write
Typical
Command
PLC3
N 1 Range Read 0 Range Write N7: 3, L5
F 1 Range Read 0 Range Write F12: 3, L5
B 1 Range Read 2 Bit Write B3/4: 5, l5
PLC5
N 1 Range Read 0 Range Write N7: 3 , L5
F 1 Range Read 67 Typed Write F12: 3, L5
B 1 Range Read 26 Read Modify Write B3/4: 5, L5
SLC5
N A2
Protected Typed Logical
Read
AA
Protected Typed Logical
Write
N7: 3, L5
F A2
Protected Typed Logical
Read
AA
Protected Typed Logical
Write
B3/4: 5, L7
B A2
Protected Typed Logical
Read
AB
Protected Typed Logical
Write
B3/4: 5, L8
I A2
Protected Typed Logical
Read
- - I: 13, L5
O A2
Protected Typed Logical
Read
- - O: 13, L5
S A2
Protected Typed Logical
Read
52: 3, L5
Appendix C.2. Error Messages
Error Message Description and Action
AB_TCP:#1 Err. Cant connect
to
%s. Recovery_Interval
begins..
This message is printed if the driver cannot open a TCP connection to the remote Node. In this
case the Node is put offline immedialy and the recovery_interval (default 30 seconds) begins.
This message is typically printed when the remote AB_TCP node is not connected to the
network or is unreachable.
