5 CONFIGURING THE FIELDSERVER AS AN ALLEN BRADLEY PCCC (TCP/IP) CLIENT
For a detailed discussion on FieldServer configuration, please refer to the FieldServer Configuration Manual. The
information that follows describes how to expand upon the factory defaults provided in the configuration files
included with the FieldServer (See “.csv” sample files provided with the FieldServer).
This section documents and describes the parameters necessary for configuring the FieldServer to communicate
with an Allen Bradley PCCC (TCP/IP) Server.
The configuration file tells the FieldServer about its interfaces, and the routing of data required. In order to enable
the FieldServer for Allen Bradley PCCC (TCP/IP) communications, the driver independent FieldServer buffers need
to be declared in the “Data Arrays” section, the destination device addresses need to be declared in the “Client
Side Nodes” section, and the data required from the servers needs to be mapped in the “Client Side Map
Descriptors” section. Details on how to do this can be found below.
Note that in the tables, * indicates an optional parameter, with the bold legal value being the default.
5.1 Client Side Connection Parameters
Section Title
Connections
Column Title Function
Legal Values
Adapter Specify which port the device is connected to the FieldServer N1
Protocol Specify protocol used AB_CSP, AB_TCP
Example
// Client Side Connections
Connections
Adapter , Protocol
N1 , AB_CSP
