FS-8704-07 Allen Bradley PCCC (TCP/IP) Driver Manual Page 8 of 15
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: [email protected]
5.3 Client Side Map Descriptors Client Side Map Descriptors
5.3.1 FieldServer Related Map Descriptor Parameters
Column Title Function Legal Values
Map_Descriptor_Name Name of this Map Descriptor Up to 32 alphanumeric characters
Data_Array_Name
Name of Data Array where data is
to be stored in the FieldServer
One of the Data Array names from Section 4.
Data_Array_Offset Starting location in Data Array
0 to (Data_Array_Length -1) as specified in
Section 4
Function Function of Client Map Descriptor Rdbc, Wrbc, Wrbx
5.3.2 Driver Related Map Descriptor Parameters
Column Title Function Legal Values
Node_Name Name of Node to fetch data from One of the Node Names specified in Section 5.2
File_Type File type in PLC N, B, F, I, O, S
3
File_Number File Number in PLC 0-65535
4
Address Starting address of read block 0-255
Data_Array_Low_Scale* Scaling zero in Data Array -32767 to 32767, 0
Data_Array_High_Scale* Scaling max in Data Array -32767 to 32767, 100
Node_Low_Scale* Scaling zero in Connected Node -32767 to 32767, 0
Node_High_Scale* Scaling max in Connected Node -32767 to 32767, 100
AB_Command Override the default command Unprotected Command Typed
3 Not all PLC’s can support all File_Types. Refer to DFS for further information.
4
Other device might not be supporting the full range, e.g. SLC5 supports only 0-255 and latest PLC5 till now supports only 0-1999
