6 OPTIONALLY HARD WIRING THE PRODUCT
6
7
8
1
2
3
4
5
9
9
10
11
18 19
15
16
17
14
12
13
12
10
A
C
B
D
Ensure the drawer is
removed and then
rotated counter-
clockwise to prevent
kinked hoses.
Remove knock-out for cable
clamp. Fit suitable cable clamp
for the conduit and terminate
the wiring as shown.
Remove Power supply
Remove the
access cover
Use copper
conductors only.
Push back the dra
wer clips
on both sides 13⁄16”(30
mm)
Before refitting the drawer,
ensure the hoses are not
twisted and the latches at
the rear of each drawer
runner are facing forward.
Ensure the drawer clips on
both sides click into place.
Ensure the drawer is
now rotated
clockwise back.
Pull fo
rward the dra
wer clips
on both sides 13⁄16”(30
mm)
Mark the placement in
case the chassis moves.
