25
• Plug the battery connector into the motor
harness connector.
Note: If the battery connector will not plug into the motor
harness connector, turn it over and try again! Do not force
the battery connector into the motor harness connector.
Battery Installation
Motor
Harness
Connector
Battery
Connector
5
• Insert the seat front tabs into the slots inside the
vehicle body.
• Then, insert the lock fastener tabs on the back of the seat
into the slots in the vehicle body.
• Using a slotted screwdriver, turn each lock fastener 1 /
4
turn
to the locked position.
IMPORTANT! Remember to keep the lock fasteners
locked at all times to prevent children from accessing
the vehicle battery compartment.
Slots
Slots
6
Seat
Locked
Lock
Fastener
Tabs
Lock Fasteners
Unlocked
