3
FTP-624MCL001/002/FTP-624DCL/DSL
For head
Voltage: 4.2 to 8.5 VDC (equivalent to 2 Lithium lon batteries)
Peak current: approx. 2.6 A (conditions: room temp., 7.2 VDC, 64 dots on)
For motor
Voltage: 4.2 to 8.5 VDC (equivalent to 2 Lithium lon batteries)
Peak current: approx. 0.8 A (conditions: room temperature, 7.2 VDC)
For logic
Voltage: 5 VDC
±
5%
Current: 0.2 A maximum
Mechanism 82 (W)
×
46 (D)
×
20 (H) mm (excluding lever and knob diameter)
Dimensions
Interface board 131 (W)
×
89 (D)
×
24 (H) mm
Weight (Mechanism) Approximately 80 g
Expected life Mechanism Pulse durability: 1
×
10 8 pulse/dot (using Fujitsu Takamisawa's standard
driving method)
Wear resistance: 50 km (at 12.5% print ratio)
Operating temperature 0 to +50
°
C* 2
Operating humidity 20 to 85% RH (no condensation)
Storage temperature –20 to +60
°
C (excluding paper)
Storage humidity 5 to 95% RH (no condensation)
Head temperature By thermistor (applied energy control, abnormal temperature detection)
Detection Paper out/Mark detect By photointerrupter
Head-up By microswitch
For front insertion use (58 mm width) : FTP-020PU001, FTP-020PG021
For rear insertion use (60 mm width) : FTP-020P0020, FTP-020PG106
Recommended thermal sensitive paper
In Europe (58 mm width) : FTP-021P0060-45
· Oji Paper : PD150R, PD160R, PD170R
· NIPPON Paper : TF50KS-E4,TF60KS-E,TF50KS-E
· MITSUBISHI Paper Mills : P220VBB-1, AFP-235
Specifications Item
(Continued)
Power
supply
Environmental
conditions
*1: There may be exceptions.
*2: Guarantee +5
°
C to +40
°
C.
