FTP-624MCL001/002/FTP-624DCL/DSL002
2
■ DESIGNATION
*1: 001 is for front paper insertion (curl path) and 002 is for rear paper insertion (straight path).
*2: 002 supports ANK, 102 supports ANK and Kanji.
*3: 002 supports ANK, 103 supports ANK and Kanji.
Part number FTP-624MCL001/002
Printing method Thermal-sensitive line dot method
Dot structure 384 dots/line
Dot pitch (Horizontal) 0.125 mm (8 dots/mm)—Dot density
Dot pitch (Vertical) 0.125 mm (8 dots/mm)—Line feed pitch
Effective printing area 48 mm
Paper width (MCL001) 58 mm
Paper width (MCL002) 60 mm
Paper thickness 60 to 100
µ
m* 1
Number of columns 48 columns/line (16
×
8 dot font)
480 dotlines/s (60 mm/s)
Conditions: 1 ply, printing on high sensitive thermal paper,
8 columns of “H” /line, double density 16
×
8 dot font,
room temperature, 8.5 VDC drive
JIS ANK : 128 International : 195
Character types ASCII : 31
24
×
12 dots, (3.0
×
1.5 mm), 32 columns
16
×
8 dots, (2.0
×
1.0 mm), 48 columns
16
×
16 dots, (4.0
×
2.0 mm), 24 columns
24
×
24 dots, (6.0
×
3.0 mm), 16 columns
Interface Centronics / RS-232C
■ GENERAL SPECIFICATIONS
Specifications Item
Maximum printing speed
Character, dimensions (H
×
W), number of
characters
(Continued)
Part number
Printer mechanism FTP-624MCL001/002* 1
RS-232C
LSI Micro Controller Unit FTP-624CU102
Thermal head cable FTP-624Y001
Parallel interface cable FTP-441Y201
Cables
Serial interface cable FTP-624Y301
Power cables FTP-621Y401
FTP621Y601
Item
FTP-624DCL002* 2
FTP-624DSL002* 3
Centronics
Interface Board
