11
■ Front Panels of the Main Unit of the Personal Computer
1 Vent
On the top of the computer there is an opening through which heat is forcibly discharged from the
computer. Note that the vent not to be blocked off by placing objects. When installing horizontally,
install the computer at a location where its surface with the vent is more than 20 cm away from the
wall.
2 Smart card bay
Smart card bay is not offered as an option.
3 Power indicator
Shows the status of the power to the main unit of the personal computer.
Lit in green when the computer is powered.
Lit in orange when the computer is in standby mode (power saving status)
4 Power supply button
Pressed in the following cases.
When the main unit of the personal computer is powered on
When the personal computer is in standby status (power saving status)
When the personal computer is resumed from standby status
12
13
14
15
1
2
3
4
5
6
7
8
9
10
11
