12 Volt Battery

12-VOLT

CHARGER

12 Volt Charger

Pb

Parts

All Shown Actual Size

.354 (Small Diameter) Cap Nut - 2*

.354"

*For your convenience, one extra .354 (small diameter) cap nut and one extra #8 x

3

/

4

" screw are included.

Note: Tighten and loosen all screws with a Phillips screwdriver. Do not over-tighten the screws.

#8 x

3

/

4

" Screw – 14*

#8 x 1

3

/

4

" Screw – 4

#6 x 1" Screw – 2
