Assembling and mounting of hull unit

The hull unit is shipped disassembled as the parts shown in the hull unit kit on
pages 1-10 and 1-11. Assemble the hull unit as shown in the procedure below.

Necessary tools

e

m

a

N

n

o

i

t

a

c

i

f

i

c

e

p

S

s

k

r

a

m

e

R

h

c

n

e

r

W

)

m

m

7

1

e

z

i

s

.

x

e

H

(

0

1

M

r

o

F

h

c

n

e

r

W

)

m

m

0

2

e

z

i

s

.

x

e

H

(

0

2

M

r

o

F

h

c

n

e

r

W

e

p

i

P

m

m

5

5

h

c

n

e

r

W

ll

a

B

m

m

4

e

z

i

s

x

e

H

t

i

k

t

i

n

u

ll

u

h

h

t

i

w

d

e

il

p

p

u

S

1. Unscrew 10 pieces of socket head cap screws with the ball wrench (supplied)

to detach the soundome.

Rotate 3 or 4 turns
by hand to make
sure that turning
mechanisms are
functioning properly.

Apply Kinoruster.

Socket head cap screw
(10 pcs, M5 x 30)

Spring washer

Protective sponge

Remove

SOUNDOME

O-ring

Kinoruster: Anti-crevice
corrosion sealant (supplied)

Figure 1-3 Detaching the soundome
