1 Front Panel Total Assy 9315335012
2 Intake Grille Assy 9315336019
4 Air Filter 9315014016
5 Clamper Grille 9306755010
6 Receiver Window 9315010018
8 Crossflow Fan Assy 9315024015
9 Bearing C Assy 9306628017
10 Casing Assy 9315331014
22 R and L Louver 9311997016
23 Spacer B 9312441013
26 Drain Cap 9367677009
27 Evaporator Assy 9315347015
28 Evaporator Assy B 9315349019
29 Connection Pipe Assy 9315354013
30 Distributor Assy 9315350015
31 Water Seal 9315251015
32 Evaporater Holder R 9314994012
33 Evaporater Holder L 9314995019
34 Rear Bracket 9315022011
35 Filter Guide 9315013019
36 Filter Guard 9315411013
37 Controller PCB Assy 9707090055
38 Control Box 9314996016
39 Control Cover 9314997013
40 Motor Case 9314998010
41 Terminal Earth 9315028013
42 DC Brushless Motor 9602163014
46 Motor, Step 9900384029
47 Motor, Step 9900384036
48 Motor, Step 9900139063
52 Gear A 9309994003
53 Terminal 9900385019
55 Indicator PCB Assy 9707210019
--- Remote Controller 9315027139
ASYA24LCC
Ref No Descriprion Ord. Q'ty
Part No
INDOOR UNIT
PARTS LIST
20 2006.02.28
