FUJITSU AOYR24LCC - Manual (Page 13)

C202
660/
450V
R200
220K
<2W>
B
B
B
B
W13
VIOLET
W12
WHITE
BLUE
YELLOW
+ C201
660/
450V
C200
660/
450V
+ +
POWER_G
B
B
N
P W7
YELLOW
W8
BLUE
SMOOTHING CIRCUIT
CAPACITOR PCB ASSY
K05DG-0500HUE-P0
Model : AOYR24LCC
12 2006.02.28
