Installing and Configuring Rack-Mounted Systems
June 2004
© 2004 Foundry Networks, Inc.
2 - 9
EXAMPLE:AR1208-T# configure terminal
EXAMPLE:AR1208-T/configure# interface ethernet 0
EXAMPLE:AR1208-T/configure/interface/ethernet 0# ip address 10.10.10.1 24
EXAMPLE:AR1208-T/configure/interface/ethernet 0# exit 2
EXAMPLE:AR1208-T/configure# interface bundle Dallas
EXAMPLE:AR1208-T/configure/interface/bundle Dallas# link ct3 1 1-10
EXAMPLE:AR1208-T/configure/interface/bundle Dallas# encapsulation ppp
EXAMPLE:AR1208-T/configure/interface/bundle Dallas# ip address 20.20.20.1 24
EXAMPLE:AR1208-T/configure/interface/bundle Dallas# exit 2
EXAMPLE:AR1208-T/configure# router routerid 10.10.10.1
EXAMPLE:AR1208-T/configure# router ospf
EXAMPLE:AR1208-T/configure/router/ospf# area 760
EXAMPLE:AR1208-T/configure/router/ospf/area 760# exit
EXAMPLE:AR1208-T/configure/router/ospf# interface Dallas area_id 760
EXAMPLE:AR1208-T/configure/router/ospf/interface Dallas# cost 10
EXAMPLE:AR1208-T/configure/router/ospf/interface Dallas# exit
EXAMPLE:AR1208-T/configure/router/ospf#interface ethernet0 area_id 760
EXAMPLE:AR1208-T/configure/router/ospf/interface ethernet0# cost 10
EXAMPLE:AR1208-T/configure/router/ospf/interface ethernet0# priority 0
EXAMPLE:AR1208-T/configure/router/ospf/interface ethernet0# exit 3
BGP4
Configuring EBGP between two different autonomous systems.
EXAMPLE:AR1208-T/configure# interface bundle Chicago
EXAMPLE:AR1208-T/configure/interface/bundle Chicago# link ct3 1 1-10
EXAMPLE:AR1208-T/configure/interface/bundle Chicago# encapsulation ppp
EXAMPLE:AR1208-T/configure/interface/bundle Chicago# ip address 20.20.20.1 24
EXAMPLE:AR1208-T/configure/interface/bundle Chicago# exit
EXAMPLE:AR1208-T/configure# router bgp 10
EXAMPLE:AR1208-T/configure/router/bgp 10# neighbor 20.20.20.2 20
EXAMPLE:AR1208-T/configure/router/bgp 10/neighbor 20.20.20.2 20# exit 3
Configuring IBGP between two neighbors in the same autonomous system.
