Foundry AR-Series Rack-Mounted Router Quick Installation Guide
2 - 2 © 2004 Foundry Networks, Inc. June 2004
Installation Site
These systems are designed to be installed in a 19- or 23-inch (48.26 or 58.42 cm) rack or on a flat, stable surface
with sufficient space to accommodate a 12- x 19-inch (30.48 x 48.26 cm) footprint. The installation site should
provide ample room for connecting cables and performing maintenance, and the site should not be subject to
extreme temperature shifts. The Foundry system should be located in close proximity to all relevant
telecommunication ports and power supplies.
Ports and Connections
The following diagrams and sections identify models and provide information about connecting AC and DC power,
network cables, and alarm and ground wires.
