Battery Installation
H
®
Important Note: Use only a Power Wheels ® Type H 6 volt
battery with a Power Wheels ® thermal fuse installed. Use of
any other battery or fuse will damage your vehicle. Make
sure that you charge the battery for at least 18 hours using
the enclosed Power Wheels
® Super 6™ Volt charger before
operating your vehicle for the first time. Charge the battery
for at least 14 hours after each use of the vehicle. Never
charge the battery longer than 30 hours. Failure to follow
these instructions may damage your battery and will void
your warranty.
2
1
®
• If the hood of the vehicle is locked, rotate the lock
fasteners 1 /
4
turn ( ) using a slotted screwdriver to
unlock it.
• Remove the hood.
• From the underside of the vehicle, fit the motor harness
connector through the opening in the battery compart-
ment wall.
• Place the Power Wheels ® Type H battery upright in the
battery compartment.
• With the looped end of the battery retainer curving up, fit
the ends of the battery retainer into the slots in the battery
compartment wall.
3
• Lower the battery retainer over the battery, and insert a
#8 x 7 /
8
" (silver) screw through the bend in the battery
retainer and into the vehicle body.
• Tighten the screw with a Phillips screwdriver. Do not
over-tighten.
LOCKED UNLOCKED
16
Lock
Fasteners
Battery
Retainer
Battery
Motor Harness
Connector
