• Fit the steering wheel cap into the center of the
steering wheel.
• Insert two #8 x 1" (black) screws into the holes in the
steering wheel cap.
• Tighten the screws with a Phillips screwdriver. Do not
over-tighten.
11
Steering Wheel Cap
Steering
Wheel
Steering Column
• Fit the top and bottom halves of the steering wheel
together.
• Insert four #6 x 1
/
2
" (pointed) screws through the holes in
the bottom half of the steering wheel and into the top
half of the steering wheel.
• Tighten the screws with a Phillips screwdriver. Do not
over-tighten.
• Insert the straight end of the steering column up through
the hole in the bottom of the steering wheel.
• Fit a cap nut onto the straight end of the steering column.
• Tap the cap nut with a hammer to secure it on the end of
the steering column.
10
Steering Wheel -
Bottom Half
Steering Wheel -
Top Half
Steering Wheel
Cap Nut
Steering
Column
8
9
Assembly
• Lower the dash on the vehicle body.
• Insert two #8 x 1" (black) screws through the holes in
the dash and into the vehicle body.
• Tighten the screws with a Phillips screwdriver. Do not
over-tighten.
Dash
11
