Light Covers
31
• Align the tabs on the inside of a light cover with the slots
in one of the light housings on the KC
TM
light rack.
Note: Make sure the light covers are positioned with the
wide tabs at the top.
• Push firmly on the light cover to snap it to the
light housing.
• Repeat this procedure on the other side of the
KC
TM
light rack to assemble the other light.
Sport Bar
KC
TM
Light
Rack - Front Half
KC
TM
Light
Rack - Back Half
Tabs
• Position the sport bar upright, as shown.
• Fit and hold the front and back halves of the KC
TM
light
rack against the sport bar. Make sure the two KC
TM
light
rack halves are aligned, and that the screw holes in the
KC
TM
light rack are aligned with the screw holes in the
canopy and the sport bar.
• Snap the tabs on the front half of the KC
TM
light rack into
the slots below the light housings on the rear half of the
KC
TM
light rack.
• Insert two #6 x1
1
/
2
" screws through the holes in the back
of the KC
TM
light rack, through the sport bar, and into the
front half of the KC
TM
light rack.
• Tighten the screws with a Phillips screwdriver. Do not
over-tighten.
30
Assembly
19
29
28
• Using safety scissors, remove the sport bar brackets from
the plastic connector. Dispose of the plastic connector.
• Position the sport bar upright.
• Fit a sport bar support through a tunnel in a rear corner
of the canopy. Make sure the ring end of the sport bar
support is positioned toward the sport bar.
• Position a sport bar bracket above one of the sport bar
side legs, as shown.
• Insert the tab on the inside of the sport bar bracket into
the hole in the sport bar side leg.
• Fit the ring on the sport bar support against the end of
the sport bar bracket.
• Fold the sport bar bracket over the sport bar to close it
around the sport bar and sport bar support.
Sport Bar Bracket
Tunnel
Sport Bar
Support
Tab
Ring
Hole
Side
Leg
• Insert a #6 x 1
1
/
2
" screw into the sport bar bracket.
• Tighten the screw with a Phillips screwdriver. Do not
over-tighten.
• Repeat steps 28 and 29 to attach the other sport bar
support to the other sport bar side leg.
Sport Bar
Bracket
Wide
Tabs
Wide Slots
