Assembly
30
• Insert the upper post into the lower post.
31
• Fit the grip halves to the post assembly, over the latch halves.
• Insert three #6 x
1 /
2
" screws into the grip halves to join all three parts
together. Tighten the screws.
Upper Post
Lower Post
Grip Halves
Latch
28
• Fit the upper post to the handle/canopy.
• Insert six #8 x
3 /
4
" screws into the upper post and tighten.
29
• Fit the latch halves to the end of the lower post.
• Insert three #6 x
1 /
2
" screws into the latch halves to join all three
parts together. Tighten the screws.
Upper Post
Handle/Canopy
Latch Halves
Lower Post
