MB39A105
5
■
■
■
■
ABSOLUTE MAXIMUM RATINGS
* : The packages are mounted on the epoxy board (10 cm
×
10 cm).
WARNING: Semiconductor devices can be permanently damaged by application of stress (voltage, current,
temperature, etc.) in excess of absolute maximum ratings. Do not exceed these ratings.
■
■
■
■
RECOMMENDED OPERATING CONDITIONS
WARNING: The recommended operating conditions are required in order to ensure the normal operation of the
semiconductor device. All of the device’s electrical characteristics are warranted when the device is
operated within these ranges.
Always use semiconductor devices within their recommended operating condition ranges. Operation
outside these ranges may adversely affect reliability and could result in device failure.
No warranty is made with respect to uses, operating conditions, or combinations not represented on
the data sheet. Users considering application outside the listed conditions are advised to contact their
FUJITSU representatives beforehand.
Parameter
Symbol
Condition
Rating
Unit
Min
Max
Power supply voltage
V
CC
VCC terminal
7
V
Output current
I
O
OUT terminal
35
mA
Output peak current
I
OP
Duty
≤
5
%
(t
=
1/f
OSC
×
Duty)
700
mA
Power dissipation
P
D
Ta
≤
+
25
°
C
490*
mW
Storage temperature
T
STG
−
55
+
125
°
C
Parameter
Symbol
Condition
Value
Unit
Min
Typ
Max
Power supply voltage
V
CC
VCC terminal
1.8
6
V
Input voltage
V
INE
−
INE terminal
0
V
CC
−
0.9
V
SCPOD terminal output voltage
V
SCPOD
SCPOD terminal
0
6
V
SCPOD terminal output current
I
SCPOT
SCPOD terminal
0
2
mA
Output current
I
O
OUT terminal
−
30
+
30
mA
Oscillation frequency
fosc
100
500
1000
kHz
Timing resistor
R
T
RT terminal
3.3
7.5
33
k
Ω
Short-circuit detection capacitor
C
SCP
CSCP terminal
0.22
1.0
µ
F
Operating ambient temperature
Ta
−
30
+
25
+
85
°
C
