MB39A105
26
■ ■ ■ ■ PACKAGE DIMENSION
8-pin plastic TSSOP
(FPT-8P-M05)
Dimensions in mm (inches)
2002 FUJITSU LIMITED F08013Sc-1-1
3.00±0.10(.118±.004)
4.40±0.10 6.40±0.20
(.252±.008) (.173±.004)
1.10(.043)MAX
0.65(.026)
0.10(.004)
0~8 ˚
0.22±0.10
(.009±.004)
0.127±0.03
(.0050±.001)
0.54(.021) 0.10±0.10
(.004±.004)
Details of "A" part
1.95(.077)
C
INDEX
1 4
5 8
"A"
