MB39A105
18
■
■
■
■
PARTS LIST
Note : SANYO : SANYO Electric Co., Ltd.
SUMIDA : SUMIDA Electric Co., Ltd.
TDK
: TDK Corporation
NEC/TOKIN : NEC TOKIN Corporation
ssm
: SUSUMU Co., Ltd.
COMPONENT
ITEM
SPECIFICATION
VENDOR
PARTS No.
Q1
Pch FET
VDS
=
20 V, ID
=
−
2 A (Max)
SANYO
MCH3306
Q2, Q3
Nch FET
VDS
=
20 V, Qg
=
4.5 nC (Typ)
SANYO
MCH3405
D1
Diode
VF
=
0.40 V (Max) , at IF
=
1 A
SANYO
SBS004
L1
Inductor
6.8
µ
H
1.4 A, 144 m
Ω
SUMIDA
CMD5D13-6R8
C1, C7, C9
C2 to C6
C8
Ceramics Condenser
NeoCapacitor
Ceramics Condenser
0.1
µ
F
4.7
µ
F
0.22
µ
F
50 V
10 V
10 V
TDK
NEC/TOKIN
TDK
C1608JB1H104K
TEPSLA21A475M8R
C1608JB1A224K
R1
R4
R5
R6
R7
R8, R11
Resistor
Resistor
Resistor
Resistor
Resistor
Resistor
7.5 k
Ω
51 k
Ω
43 k
Ω
330 k
Ω
22 k
Ω
100 k
Ω
0.5
%
0.5
%
0.5
%
0.5
%
0.5
%
0.5
%
ssm
ssm
ssm
ssm
ssm
ssm
RR0816P-752-D
RR0816P-513-D
RR0816P-433-D
RR0816P-334-D
RR0816P-223-D
RR0816P-104-D
