4.3. Client Side Node Descriptors
Section
Title
Nodes
Column
Title
Function Legal Values
Node_Name Provide name for node
Up to 32
alphanumeric
characters
Node_ID
Modbus station address of physical server node.
These correspond to the ‘devices’ configured in the
DTPConfig. Thus the Node_ID is not the address of
the final CCN device.
The DataLink DTPConfig table maps a device number
(1..15) to a bus number (0-239). Use the Node_ID to
tell the driver which device to use.
1-15
Protocol Specify protocol used CarrierDL
Port
Specify which port the device is connected to the
FieldServer
P1-P8, R1-R2 2
Example
// Client Side Nodes
Nodes
Node_Name, Node_ID, Protocol , Port
FAN1 , 1 , CarrierDL, P8
4.4. Client Side Map Descriptors
4.4.1. FieldServer Related Map Descriptor Parameters
Column Title Function Legal Values
Map_Descriptor_Name Name of this Map Descriptor
Up to 32 alphanumeric
characters
Data_Array_Name
Name of Data Array where
data is to be stored in the
FieldServer One of the Data Array names
from “Data Array” section
above
Data_Array_Location
Starting location in Data
Array 0 to maximum specified in
“Data Array” section above
Function
Function of Client Map
Descriptor
RDBC, WRBC, WRBX
2
Not all ports shown are necessarily supported by the hardware. Consult the appropriate Instruction
manual for details of the ports available on specific hardware.
