FS-8700-82 Carrier DataLink Page 7 of 31
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com
Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: [email protected]
Example
// Data Arrays
Data_Arrays
Data_Array_Name, Data_Format, Data_Array_Length
DA_AI_01, UInt16, 200
DA_AO_01, UInt16, 200
DA_DI_01, Bit, 200
DA_DO_01, Bit, 200
4.2. Client Side Connection Descriptions
Section Title
Connections
Column Title Function Legal Values
Port
Specify which port the device is connected to the
FieldServer
P1-P8, R1-R2 1
Baud* Specify baud rate
300, 600 , 1200,
2400, 9600 (Vendor
limitation)
Parity* Specify parity.
None (Vendor
Limitation)
Data_Bits* Specify data bits 8 (Vendor Limitation)
Stop_Bits* Specify stop bits 1 (Vendor limitation)
Protocol Specify protocol used CarrrierDL
Handshaking* Specify hardware handshaking None
Poll _Delay* Time between internal polls
0-32000 seconds, 1
second
Timeout*
When reading entire tables it is recommended that
the timeout be set to between 15 and 30 seconds.
Additional information is provided in Appendix A.5
0.1 to 60.0 seconds,
2.0seconds
IC_Timeout*
When reading entire tables it is recommended that
the ic_timeout be set to approx 15.0 seconds.
Additional information is provided in Appendix A.5
Example
// Client Side Connections
Connections
Port, Baud, Parity, Data_bits, Stop_Bits, Protocol,
Handshaking, Poll_Delay
P8, 9600, None, 8 , 1 , CarrierDL, None , 0.100s
1
Not all ports shown are necessarily supported by the hardware. Consult the appropriate Instruction
manual for details of the ports available on specific hardware.
