background image

FS-8700-16 BACnet PTP Serial Driver Manual

Page 14 of 32

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll Free: (888) 509-1970 email: [email protected]

Example

// Server Side Nodes

Nodes

Node_Name

, Node_ID , Protocol

4

Virtual_DEV_11 , 11

, BACnet_PTP

5.5

Server Side Map Descriptors

5.5.1 FieldServer Specific Map Descriptor Parameters

Column Title

Function

Legal Values

Map_Descriptor_Name

Name of this Map Descriptor. This is used for
Object_Name Property. Refer to Appendix A.1.

Up to 32 alphanumeric characters

Data_Array_Name

Name of Data Array where data is to be stored
in the FieldServer

One of the Data Array names from
“Data Arrays” section

Data_Array_Offset

Starting location in Data Array

0 to (“Data_Array_Length” -1)

Function

Function of Server Map Descriptor

Passive

4 Note that Port is not declared in the Server Side Nodes
