9
EN
1
Hardware Installation
How the keycard protection works:
Hard Drive
Secure locked
unlock Hard Drive
Secure with keycard
over the sensor in the
front side of the drive
Hard Drive Secure
unlocked
Move keycard over
the sensor
Hard Drive Secure
locked
To configure the 2 keycards using the "Freecom Hard Drive Keycard Protection" software
assistant, see chapter 4.
1. Front view
1. RFID sensor (invisible, is placed behind the black front bezel)
2. Left LED (green/red)
3. Right LED (white)
1. RFID sensor
This is the position where the keycard needs to be held to unlock the drive.
2. Left LED (green/red)
LED off:
keycard protection not configured
LED red, flashing quickly: waiting for initial recognition of the first
Keycard
1. 2. 3.
