AP-6

Board Switch

Setting

Function

Factory

setting

#1

#2 Ship’s speed for distance run pulse selection

OFF OFF

Speed over-the-ground & through-water & speed
fed from nav sensor

OFF

ON Speed over-the-ground & through-water

ON -

Speed

through-water

OFF Type of ship’s speed for distance run pulse: Vector

#3

ON Ditto : Fore-aft

OFF Bearing data output: True course

#4

ON Ditto : Heading

OFF Bearing data output at low Ship’s speed: True course

#5

ON

Ditto :Heading
(Since ship’s course data fluctuates by rolling and
pitching when ship’s speed is extremely low,
heading data is output instead of course. )

OFF Distance signal alarm Contact: ON = No alarm

#6

ON Fore-aft status Contact: ON = Aft (note 1)

OFF CIF/NMEA 1 option data: Off

#7

ON Ditto : On (Note 2.)

OFF CIF/NMEA 2 option data: Off

S4

#8

ON Ditto : On (Note 2.)

S5 0 to F

Engine revolution full scale setting.

0

Rate-of turn gyro data averaging time: 10 mses

1

Ditto

:

20mses

2

Ditto

:

40mses

3

Ditto

:

80mses

4

Ditto

:

160mses

5

Ditto

:

230mses

6

Ditto

:

640mses

MIF Board

S6

7 to F

Ditto

:

1280mses

Note 1: Prior to setting #6 to “ON”, set #3 to “ON”.

Note 2: DRU (Dual Doppler Auxiliary Data) and VWT (True Wind Speed and Angle) are outputted.
