Technical Data
QC11
QC600
BQF 40
Nominal Chilling Capacity
11Kg
40Kg
Duty @ -15°C
830w
1031w
Fans
1
2
Defrost Load
N/A
N/A
Evaporating Temperature
-15°C
-15°C
Refrigerant Control
TEV
TEV
Refrigerant
R404a
R404a
Refrigerant Quantity
1000g
TBA
Electrical Supply
230/1/50 – 13amp
230/1/50 – 13amp
Total Heat Rejection
1500w
2080w
Wiring Diagram Numbers
Model
Wiring Diagram Number
Fuse Rating
QC 11
01-233728
13 Amp
QC 600
01-233729
13 Amp
BQCsF 40
13 Amp
