PrP: Printer presence. (Yes or no) Enables or disables the printer.
ItP: Printing interval. (0.0 to 30.0). Sets the print interval.
PbP: Print probe selection. (iP: only the food probe selected. rP: only the air probe selected. irP: Food and Air
probe selected. irE: All probes selected).
PtH: (yes or no) Enables or disables the printing during the holding phase.
tSt: Starts the controller self test function.
Out: Exit from the menu.
Parameter Access and modification
To access the parameters firstly enter the function menu by pressing the “SET” and “DOWN” keys for 3 seconds.
Scroll through the labels and select “PR2”, press the “SET” key. “PAS” label flashes for a few second followed by
“0 _ _” with the zero flashing. The access code is ‘ 321’.
Use the “UP” or “DOWN” key to input the first number of the security code in the flashing section, confirm by
pressing “SET”.
Repeat the operation for the second and third digits.
If the security code is correct “Hy” will be displayed.
NOTE: if no key is pressed for 15 seconds the controller reverts to displaying the room temperature.
Parameter Settings
Lab Description Default QC 11 QC 600 BQCF 40
Regulation
Hy differential 3 3 3 3
AC Anti-short cycle delay 2 2 2 2
1c2 Second compressor configuration 0 0 0 0
rPO Thermostat probe calibration 0 0 0 0
EPP Evaporator probe presence YES NO YES YES
EPO Evaporator probe calibration 0 0 0 0
iPP Insert probe presence YES YES YES YES
iPO Insert probe calibration 0 0 0 0
CF Temperature measurement unit °C °C °C °C
rES Resolution (for °C): IN IN IN IN
PAU Time of stand by 1 1 1 1
PFt Maximum acceptable duration of power failure 2 2 2 2
iPd Temperature difference for the automatic recognition of the insert probe 3 3 3 3
iPt Time delay for the automatic recognition of the insert probe 60 60 60 60
Con Compressor ON time with faulty probe 15 15 15 15
COF Compressor OFF time with faulty probe 10 10 10 10
diC Digital input operating mode dor dor dor Dor
diP Digital input polarity OP OP OP OP
did Digital input delay 5 5 5 5
OAC Auxiliary output configuration AL AL AL AL
OAP Auxiliary output polarity OP CL CL CL
OAt AUX output timer 60 60 60 60
OAS Set point for AUX output 0 0 0 0
OAH Differential for AUX output 2 2 2 2
OAi Probe selection for the AUX output rP rP rP rP
Defrost
tdF Defrost type in in in In
dPO Defrost before holding cycle YES YES YES YES
IdF Interval between defrost cycles 6.0 6.0 6.0 6.0
dtE Defrost termination temperature 20 20 20 20
MdF Maximum length for defrost 20 20 20 20
dFd Temperature displayed during defrost rt rt rt Rt
Fdt Drip time 1 1 1 1
Fans
FnC Fan operating mode c_n O_Y O_Y O_Y
FSt Fan stop temperature 30 30 30 30
AFH Differential for the stop temperature and for the alarm 2 2 2 2
Fnd Fan delay after defrost 2 2 2 2
